| PART NO. | THREAD E | HOSE BORE (DN) (DN) | HOSE BORE (DASH) | DIMENSIONS (C) | DIMENSIONS (S2) | DIMENSIONS (S1) | DIMENSIONS (A) |
| 26711D-04- 04SM | 7/16" × 20 | 6 | 4 | 20 | 9 | 12 | 15 |
| 26711D-05-04SM | 1/2" × 20 | 6 | 4 | 20.5 | 9.5 | 12 | 17 |
| 26711D-06- 04SM | 9/16" × 18 | 6 | 4 | 21 | 10.5 | 14 | 19 |
| 26711D-06-06SM | 9/16" × 18 | 10 | 6 | 21 | 10.5 | 17 | 19 |
| 26711D-08-06SM | 3/4" × 16 | 10 | 6 | 23 | 11 | 19 | 24 |
| 26711D-08-08SM | 3/4" × 16 | 12 | 8 | 24.5 | 11 | 22 | 24 |
| 26711D-08-10SM | 3/4" × 16 | 16 | 10 | 25.5 | 11 | 22 | 24 |
| 26711D-10-08SM | 7/8" × 14 | 12 | 8 | 24 | 13 | 22 | 27 |
| 26711D-10-10SM | 7/8" × 14 | 16 | 10 | 27 | 13 | 22 | 27 |
| 26711D-12-12SM | 1.1/16" × 12 | 20 | 12 | 31.5 | 15 | 27 | 32 |
| 26711D-16-12SM | 1.5/16" × 12 | 20 | 12 | 31.5 | 16 | 32 | 41 |
| 26711D-16-16SM | 1.5/16" × 12 | 25 | 16 | 32.5 | 16 | 32 | 41 |
| 26711D-20-20SM | 1.7/16" × 12 | 32 | 20 | 37 | 17 | 41 | 50 |
