| PART NUMBER | OD | DN | DASH | C | S | H | |
| 22291-04-04 | G1/4"× 19 | 6 | 04 | 8 | 19 | 34 | |
| 22291-06-05 | G3/8"× 19 | 8 | 05 | 9 | 22 | 38.5 | |
| 22291-06-06 | G3/8"× 19 | 10 | 06 | 9 | 22 | 40.8 | |
| 22291-08-08 | G1/2"× 14 | 12 | 8 | 10.5 | 27 | 48 | |
| 22291-10-10 | G5/8"× 14 | 16 | 10 | 12 | 30 | 54 | |
| 22291-12-12 | G3/4"× 14 | 20 | 12 | 13.5 | 32 | 63.5 | |
| 22291-16-16 | G1"× 11 | 25 | 16 | 15.5 | 41 | 70 | |
| 22291-20-20 | G1.1/4"× 11 | 32 | 20 | 15.5 | 50 | 82.5 | |
| 22291-24-24 | G1.1/2"× 11 | 38 | 24 | 17.5 | 55 | 97.5 | |
| NOTE: 1. FOR USE WITH BRAIDED HOSES. 2. IF USE WITH SPIRAL HOSES, HOSE FITTINGS SERIES NUMBER IS 22292-XX-XX. |
|||||||
