| PART Number | THREAD E | HOSE BORE | DIMENSIONS | |||||
| DN | DASH | A | C | H | S2 | |||
| 20611-14-04 | M14 × 1.5 | 6 | 04 | 27.5 | 5.5 | 37 | 19 | |
| 2011-16-05 | M16 × 1.5 | 8 | 05 | 31 | 5.5 | 42 | 22 | |
| 20611-18-06 | M18 × 1.5 | 10 | 06 | 33 | 5.5 | 44.5 | 24 | |
| 20611-22-08 | M22 × 1.5 | 12 | 08 | 42.5 | 6 | 53.5 | 27 | |
| 20611-27-10DT | M27 × 1.5 | 16 | 10 | 56 | 6 | 55 | 32 | |
| 20611-30-12D | M30 × 2 | 20 | 12 | 66.2 | 6 | 68.5 | 36 | |
| 20611-36-16 | M36 × 2 | 25 | 16 | 78 | 6.5 | 76.5 | 41 | |
| 20611-36-14T | M36 × 2 | 22 | 14 | 71.2 | 6.5 | 67.5 | 41 | |
| 20611-39-16T | M39 × 2 | 25 | 16 | 76.7 | 6.5 | 74 | 46 | |
| 20611-45-20T | M45 × 2 | 32 | 20 | 91.5 | 8.5 | 85 | 55 | |
| 20611-52-24T | M52 × 2 | 40 | 24 | 109.4 | 10 | 99 | 60 | |
| NOTE: 1. FOR USE WITH BRAIDED HOSES. 2. IF USE WITH SPIRAL HOSE, HOSE FITTINGS SERIES NUMBER IS 20692-XX-XX. |
||||||||
